The Trail Master Blazer4 200EX is a superior upgrade from the Blazer4 150X, featuring a powerful 169cc GY6 engine with EFI. The fuel injection system ensures easy starts in cold weather or high altitudes and eliminates the need for carburetor maintenance after periods of inactivity.

This full-size, 4-seat go-kart accommodates up to four adults, boasting a heavy-duty frame with a net weight of 578 lbs and a maximum load capacity of 800 lbs. Both front driver and passenger seats are adjustable, with the driver side offering a pedal-to-seat back adjustment from 36” to 42”, comfortably fitting individuals up to 6’2” in height. The front seat to rear seat distance is 26”, allowing ample space for rear passengers up to 6’2” tall.

Equipped with larger front and rear tires (20 x 7-8 / 21 x 10-10) and a special gear ratio, the Blazer4 200EX delivers plenty of power for smooth take-offs and the ability to pull four people. With a top speed of up to 38 MPH, this go-kart combines performance and comfort, making it the perfect choice for family adventures.

Key Features:

• Fuel injection system operates under any weather and at any altitude
• Fully automatic with reverse, high performance 169cc GY6 engine with internal F-N-R
• Special gear ratio set up, plenty of power to take off and pull 4 people.
• Top speed can reach up to 38 M/H.
• Stylish design
• Electric start with kill switch
• Heavy duty frame, net weight 728 lbs, max load 800 lbs, adult size 4-seat go kart
• Front seat to rear seat distance 26 inches, fits passengers up to 6’2 in height
• Adjustable front driver and passenger seat: pedal to seat back adjustable from 36” to 42”, fits driver/passenger up to 6’2 in height
• Digital speedometer/odometer
• Aluminum side mirrors
• Turn signals
• 5-Point safety harness seatbelt
• Individual sporting seats
• Big tires: F / R: 20 x 7-8 / 21 x 10-10
• Bikini sunshade top
• Adjustable heavy duty front and rear shock absorber
• Rack and pinion steering wheel
• Front and rear hydraulic disc brake
• 4-wheel fenders
• Trailer hitch
• Large gas tank
• LED headlight
• Horn
• Padding over roll cage

SPECIFICATIONS

Certification:	EPA certificated
Engine Type:	4-stroke, single cylinder, air cooled
Displacement:	168.9cc
Max Horsepower:	11.1hp/8000rpm
Max. Torque:	8.1 lb ft/6000rpm
Bore Stroke:	2.4x2.28 inches
Max speed:	38 mph
Climbing Ability:	18 degrees
Min turning radius:	229 inches
Ignition:	ECU
Starting System:	Electric
Battery:	12V 10Ah
Carburetor Brand:	Deli
Engine Oil:	SAE 15W/40
Clutch:	Automatic CVT with reverse
Driveline / Driving wheel:	Chain / Dual wheel drive
Suspension F/R:	Dual A-arm / swing-arm
Brakes, F/R:	Hydraulic Disc
Tires F/R:	20 x 7-8 / 21 x 10-10
Fuel capacity:	2.25 gal
Gross Weight:	850 lbs
Net Weight:	728 lbs
Max Load:	800 lbs
Wheelbase:	88 inches
OA L x W x H:	116.1x54.5x55.5 inches
Height to Seat, F/R:	17 inches/ 20 inches
Distance from F to R seat:	26 inches
Min Ground Clearance	15.8 inches
Pedal to seat back distance:	36-42 inches

Configurations And Specifications Subject To Change Without Notice.
